Connectors | |
RJ-45 10/100/1000 Ports | 48 |
SFP28 Uplink Ports | 6 |
Console Ports | 1 x RJ45 |
Remote Console | 1 X RJ45 |
USB Port | 1 |
Performance | |
Switching Capacity | 396 Gbps |
Forwarding Rate | 295 Mpps |
Flash Memory | 256 MB |
DRAM | 1GB |
MAC Address Table Size | 32K |
Jumbo Frames | 10 KB |
Auto-negotiation | Yes |
Maximum Input Power Rating | 100-240V AC,50-60Hz |
Power Consumption | 54W (MAX) 177BTU/h Note: ● The measurement in Watts indicates the typical power consumption of the device with no external loading. ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
Environmental | |
Operating Temperature | -5–45°C |
Storage Temperature | -40–70°C |
Humidity | 5%–95% RH, Non-condensing |
Physical Properties | |
Rack Space | 19" |
Housing | Metal |
Weight | 4.68 kg ( 10.32 lb ) |
Dimensions (L x W x H) | 44.20 x 42.00 x 4.36 cm (17.4 x 16.54 x 1.72 in.) |
Carton Lot | 1 pc |
